Panel Types

Swing Down

  • Convenient swing-down panels clip-attach directly to standard 15/16" suspension system

Lay-In

  • Designed to rest in standard 15/16" suspension system

Techstyle® Grid System (Echelon)

Key Features

  • Unique construction combining high quality, smooth surfaces and channeled honeycomb fiberglass core

  • High light reflectance up to 81% for brighter spaces with less energy costs. (white only)

  • Monolithic appearance – large format panels, semi-concealed suspension, nominal ¼" reveals

  • Trims are engineered for fast installation of Techstyle®

  • Lighting and diffuser integration

  • GREENGUARD Gold Certified formaldehyde free

Physical Data

  • Surface Finish:

    • White - Fiberglass matte surface

    • Color, Wood, and Custom - Polyester non-woven fabric surface

    • Felt - Polyester non-woven fabric surface

  • Light Reflectance: 81% (LR1) ASTM E1477 (Techstyle White)

  • Fire Class: Class A Fire Rating, per ASTM E 84 & CAN S102

  • Acoustical Ratings - NRC: 0.85 (ASTM C 423)

  • Acoustical Ratings - CAC: 17 w/no backer (ASTM E1414)

  • Moisture Resistance: Resistant to 95% humidity in 104°F temperature

  • Weight: 0.30lbs/sf for swing down and 0.24lbs/sf for lay-in panels

  • Warranty: 10-year limited
